Avigilon Unity AC-LSP-4DR-MER-LCK Access Control Manager
Equipment Overview
Equipment Category
Processing Equipment
Select Region
USA
Model Number
AC-LSP-4DR-MER/LCK
Reference Price (Per Unit)
CAD $982.00
* The "Reference Price" is an indication of what the seller paid. This is not a "Buy Now" price. The Reference Price guides bidders to place offers below it in our marketplace, ensuring the winning bid remains lower than the listed reference price.
Date of Invoice
2025
State
Colorado
Quantity
1
Hours of Use
Not used
Description
LifeSafety Power four door Mercury Dual Voltage Integrated Power System 1 Four Door Mercury Dual Voltage Integrated Power System supporting one AC-MER-CONT-LP1502 with one AC-MER-CON-MR52. The advantage of a dual voltage power supply is the ability to power both Mercury boards and door locks from the same supply. Includes a painted steel enclosure, removable pre drilled back plate, controller standoffs and mounting screws and a 75 watt 12V/2A and 24V/2A power supply-battery charger. The power supply is pre-wired to eight Class 2, Power Limited (CL2PL) outputs (D8P Board) delivering a regulated independent power connection to each Mercury board and four fused output (C4 Board) for independent relay lock power. The power supply features dual outputs (12 & 24 volts DC), form "C" fault relay contacts, a fire alarm input and network interface (interface module sold separately) to enable monitoring, reporting and control of the power system from Access Control Manager (ACM) link. Battery space for two 12V, 8Ah batteries is available in cabinet. Cabinet size: 16" x 20" x 4.5" with door lock and two (2) keys. Weight 25 lb. (LifeSafety Power Part Number: FPO75-B100C4D8PE2M )
