POLYSCIENCE CHILLER 6860T56AB50D
Equipment Overview
Equipment Category
Processing Equipment
Select Region
Canada
Model Number
6860T56AB50D
Reference Price (Per Unit)
CAD $11,060.00
* The "Reference Price" is an indication of what the seller paid. This is not a "Buy Now" price. The Reference Price guides bidders to place offers below it in our marketplace, ensuring the winning bid remains lower than the listed reference price.
Date of Invoice
2017
Province
British Columbia
Quantity
1
Hours of Use
500-800
Description
Working Temperature Range °F : 41° to 95° Working Temperature Range °C : 5° to 35° Reservoir Capacity (gallons) : 3.5 Reservoir Capacity (liters) : 13.25 Reservoir/Tank Material : Polyethylene Reservoir Cover : Screw-on Cap Cleanable Air Filter : Yes Cleanable Fluid Filter : Yes Temperature Stability °F : ±0.9° Temperature Stability °C : ±0.5° Display : LED Display Resolution (Read) : 0.1 Pump Type : Turbine Process Connections : 1/2" (F) NPT Over-Temperature Protection / Failsafe Heater Control : Yes Reservoir Liquid Level Indicator : Yes Reservoir Drain : Yes Maximum Ambient Temperature °F : 95° Maximum Ambient Temperature °C : 35° Overall Dimensions (L x W x H) (inches) : 30.5 x 19 x 26 in Overall Dimensions (L x W x H) (cm) : 78 x 48 x 66 cm Compressor Size (HP) : 1.5 Refrigerant : R134a Shipping Weight (pounds) : 340 Shipping Weight (kilograms) : 154 Catalog Page Number : 104 Part Number : 6860T56A270D Maximum Pressure (psi) : 100 Maximum Pressure (bar) : 6.9 Maximum Pressure Flow Rate (gpm) : 11 Maximum Pressure Flow Rate (l/min) : 41.6 Cooling Capacity @ +10°C (W) : 4420 Cooling Capacity @ +20°C (W) : 5200 Cooling Capacity @ +30°C (W) : 5980 Heater Wattage : 1000 Electrical Requirements (VAC/Hz/Ph/A) : 230/60/1/23.1 Regulatory Approvals : TUV SKU ：6860T56AB50D PolyScience DuraChill -10C 80C 13L 1.5HP Chiller w/ Turbine Pump; Air-Cooled. 230V/60H/1 Phase/23.1A 3/4HP Turbinne Pump Refrigerant Rype R134a. Cooling Capacity 5,200W @20oc
